Enclosed Top Mount Pumper
Custom built for Trout Lake Fire Department — Trout Lake, MN
Spartan Chassis, Bolted Stainless Steel Body, Waterous 1250gpm Pump, FoamPro 2001 Foam System, 1200-Gallon Water Tank, Adjustable Compartment Shelving, Pull-Out Compartment Trays, Tool Board, Wheel Well SCBA Cylinder Storage, Slide-In Ladder Storage, Swing-Out and Down Ladder, Overhead Coffin Style Compartments, LED Emergency Lighting
Truck Type : Pumpers
Cab Type : Custom Cab, Enclosed Top Mount
Deployed : January, 2020
Chassis Model
Spartan MetroStar Chassis
Cummins L9 450hp Engine
Allison 3000 EVS Transmission
Apparatus Body
Concealed Bolted Construction
Stainless Steel Body Material
Stainless Steel Subframe
Roll-Up Compartment Doors
Fire Pump System
Interior Pump Control Panel
Waterous CSC20 1250gpm Midship Mounted Pump
FoamPro 2001 Single Agent Foam System
Fire Research PumpBoss Pressure Governor
Trident Pump Air Primer
Passenger Side 6" and 2-1/2" Suctions
Rear 6" Suction
Driver Side 6" Suction
Front Bumper 2" Preconnect Discharges
Passenger Side 2-1/2" and 4" Discharges
Hosebed 2-1/2" Preconnect Discharge
Driver Side 2-1/2" Discharge
Top Deluge Discharge
Forward and Rearward Speedlay Discharges
Booster Tank
1200-Gallon Water Tank
30-Gallon Foam Cell
Special Features
Front Bumper Extension with Crosslay Hosebed
Adjustable Compartment Shelving
Pull-Out Compartment Trays
Fixed Pegboard Tool Board
Swing-Out Tool Board
Custom Tool Box
Wheel Well SCBA Cylinder Storage
Slide-In Ladder Storage
Swing-Out and Down Rear Access Ladder
Overhead Storage Coffin Compartments
Emergency Warning Devices
LED Emergency Lights
Whelen LED Lightbar
Whelen Siren Control Head
Mechanical Siren
Exterior Lighting
LED Compartment Lights
LED Tail Lighting
Under Body and Under Cab Lights
Whelen LED Scene Lights
Vehicle Dimensions
Overall Height 11' 3"
Overall Length 37' 1"
Wheelbase 18' 4"
Weight with Water 42,730 Lbs.
