Truck Type : Pumpers, Sourcewell Deliveries, Tenders
Cab Type : Commercial Cab, Less Than 2300 Gallons
Deployed : April, 2025

Chassis Model

Kenworth T480 Chassis
Paccar PX9 450hp Engine
Allison 3000 EVS Transmission
50,000 Lbs. GVWR

Apparatus Body

Concealed Bolted Construction
Stainless Steel Subframe
Stainless Steel Material

Fire Pump System

Waterous CGVGPA 750 PTO Driven Water Pump
FoamPro 1600 Foam System
Fire Research PumpBoss Pressure Governor
Trident Air Pump Primer
Passenger Side 6" and 2.5" Suctions
Driver Side 6" Suction
Forward and Rearward 2" Crosslay Discharges

Booster Tank

2000-Gallon Water Tank
Rear Dump Chute

Special Features

Adjustable Compartment Shelving
Dual Crosslay Hosebeds
Slide-In Suction Hose Storage
Wheel Well SCBA Cylinder Storage
Slide-In Ladder Storage & Pike Pole Storage
Drop-Down Portable Tank Storage
Rear Observation & Audio Monitoring System

Emergency Warning Devices

Air Horns of Texas Air Horns
Whelen Electronic Siren and Speakers
Whelen LED Freedom Lightbar
Whelen LED Warning Lights

Exterior Lighting

Vertical Strip Compartment LED Lighting
LED Marker Lights
Whelen LED Lights
Under Cab and Under Body Lights
Whelen LED Scene Lights

Vehicle Dimensions

Overall Height 9' 8"
Overall Length 31' 5"
Wheelbase 226.75"
Weight with Water 41,470 Lbs.
