Open Top Mount Pumper
Custom built for Lawrence Fire Department — Lawrence, WI
Spartan Chassis, Bolted Body, Waterous 1500gpm Pump, FoamPro 2001 Foam System, Adjustable Shelving, Pull-Out Compartment Trays and Tool Boards, Slide-In Ladder and Pike Pole Storage, 1000-Gallons Water Tank
Truck Type : Pumpers
Cab Type : Custom Cab, Open Top Mount
Deployed : December, 2015
Chassis Model
Spartan Chassis
Cummins ISL 450hp Engine
Allison 3000 EVS Transmission
Apparatus Body
Concealed Bolted Construction
Stainless Steel Material
Roll-Up Compartment Doors
Fire Pump System
Waterous CSUC20 1500gpm Midship Pump
FoamPro 2001 Single Agent Foam System
Fire Research PumpBoss Pressure Governor
Waterous Oil-Less Pump Primer
Passenger Side 6" and 2-1/2" Suctions
Driver Side 6" Suction
Passenger Side 2-1/2" and 3-1/2" Discharges
Rear 2-1/2" and 4" Discharges
Driver Side 2-1/2" Discharges
Top Deluge Discharge
Front Bumper 2-1/2" Preconnect Discharge
Top and Bottom 2" Speedlay Discharges
Booster Tank
1000 Gallons of Water
20 Gallons of Foam
Special Features
Front Bumper Extension with Hosewell
Adjustable Compartment Shelving
Pull-Out Compartment Trays
Pull-Out Tool Boards
Ziamatic Helmet Holders
Encapsulated Roll-Up Door Protection
Hard Suction Hose Storage Sleeve
Hard Suction Hose Troughs
Slide-In Ladder and Pike Pole Storage
Folding Ladder Slide-In Tray
SCBA Cylinder Storage Rack
Emergency Warning Devices
Federal Electronic Siren
Whelen LED Traffic Advisor
Whelen LED Warning Lights
Exterior Lighting
LED Marker Lights
Under Body and Under Cab Lights
LED Vertical Strip Compartment Lighting
Vehicle Dimensions
Height 9' 8"
Length 33' 10"
Wheelbase 16' 7"
Weight with Water 39,120 Lbs.
