Enclosed Top Mount Pumper
Custom built for La Valle Fire Department — La Valle, WI
Spartan MetroStar Chassis, Bolted Stainless Body, Waterous 1250gpm Pump, 900-Gallon Tank, Front Bumper Extension with Hosewell and Suction Hose, Adjustable Compartment Shelving, Pull-Out Compartment Trays, Wheel Well SCBA Cylinder Storage, Wall-Mounted SCBA Brackets, Hydraulic Drop-Down Ladder Rack, LED Emergency Lighting
Truck Type : Pumpers
Cab Type : Custom Cab, Enclosed Top Mount
Deployed : April, 2019
Chassis Model
Spartan MetroStar Chassis
Cummins L9 450hp Engine
Allison 3000 EVS Transmission
Apparatus Body
Concealed Bolted Construction
Stainless Steel Body Material
Stainless Steel Subframe
Roll-Up Compartment Doors
Fire Pump System
Waterous CSC20 1250gpm Midship Pump
Waterous Oil-Less Pump Primer
Fire Research PumpBoss Pressure Governor
Suction Pre-Primes
Front 6" Suction
Passenger Side 6" and 2-1/2" Suctions
Driver Side 6" Suction
Front Bumper Preconnect Discharge
Forward and Rearward 2" Crosslay Discharges
Passenger Side 2-1/2" and LDH Discharges
Rear 2-1/2" Discharge
Driver Side 2-1/2" Discharge
Deluge Discharge
Booster Tank
900-Gallon Water Tank
Special Features
Front Bumper Extension with Hosewell
Dual Crosslay Hosebeds with Hinged Cover
Adjustable Compartment Shelving
Pull-Out Compartment Trays
Well Wheel SCBA Cylinder Storage
Wall Mounted SCBA Brackets
Hydraulic Drop-Down Ladder Rack
Encapsulated Roll-Up Door Protection
Powermax On-Board Battery Charger
Emergency Warning Devices
Whelen LED Warning Lights
Whelen LED Lightbar
Whelen Electronic Siren and Speaker
Exterior Lighting
Vertical Strip Compartment Lights
LED Marker Lights
Techniq LED Tail Lights
Under Body and Under Cab Lights
Fire Research Telescoping Floodlights
Vehicle Dimensions
Overall Height 10' 8"
Overall Length 33' 8"
Wheelbase 15' 5"
Weight with Water 34,430 Lbs.
