Initial Attack

Custom built for Grovespring Area Vol. Fire Prot. Assoc. — Grovespring, MO

Ford F550 Chassis, Bolted Stainless Steel Body, Waterous 1000gpm Rear Mounted Pump, Hale FoamLogix Foam System, 300-Gallon Water Tank, Adjustable Compartment Shelving, Pull-Out Tool Boards, Hard Suction Hose Troughs, LED Emergency Lighting

Truck Type :
Cab Type :
Deployed : August, 2017

Chassis Model

Ford F550 Chassis
PowerStroke 330hp Engine
Automatic Transmission

Cab Details

SCBA Seating
Helmet Storage
EMS Cabinet

Apparatus Body

Concealed Bolted Construction
Stainless Steel Material
Stainless Steel Subframe
Hinged Compartment Doors

Fire Pump System

Waterous CXD 1000gpm Rear Mounted Pump
Hale FoamLogix Single Agent Foam System
Fire Research PumpBoss Pressure Governor
Waterous Oil-Less Pump Primer
Rear 6" and 2-1/2" Suctions
Rear 2-1/2" Discharges
Hosebed 2" and 2-1/2" Discharges

Booster Tank

300-Gallon Poly Water Tank
20-Gallon Foam Cell

Special Features

Front Bumper Winch Receiver
Under Body Winch Receivers
Adjustable Compartment Shelving
Pull-Out Tool Boards
Wheel Well SCBA Cylinder Storage
Hard Suction Hose Troughs
On Board Battery Charger

Emergency Warning Devices

Whelen Electronic Siren and Speaker
Whelen LED Lightbar
Whelen LED Warning Lights

Exterior Lighting

Vertical Strip Interior Compartment Lights
LED Marker Lights
Whelen Tail Lights
Under Body and Under Cab Lights
Rigid Industry LED Scene Lights

Vehicle Dimensions

Overall Height 8' 5"
Overall Length 25' 9"
Wheelbase 16'
Weight Empty 14,390 Lbs.
