Truck Type : HGACBuy Deliveries, Pumpers
Cab Type : Custom Cab, Enclosed Top Mount
Deployed : January, 2023

Chassis Model

Spartan Metro Star Chassis
Cummins L9 450hp Engine
Allison 3000 EVS Transmission
49,000 Lbs. GVWR

Apparatus Body

Concealed Bolted Construction
Stainless Steel Body
Stainless Steel Subframe
Roll-Up Compartment Doors

Fire Pump System

Waterous CSUC20 1500gpm Midship Mounted Pump
FoamPro 2001 Foam System
Fire Research PumpBoss Pressure Governor
Trident Air Pump Primer
Suction Pre-Primes
6" and 2.5" Passenger Side Suctions
6" Rear Suction
6" Driver Side Suction
2.5" and 4" Passenger Side Discharges
2.5" Rear Discharges
2.5" Driver Side Discharge
Top Deluge Discharge
2.5" Front Bumper Preconnect Discharge
2.5" Top and Bottom Speedlays

Booster Tank

1000-Gallon Water Tank
20-Gallon Foam Cell

Special Features

Adjustable Compartment Shelving
Pull-Out Compartment Trays
Swing-Out Tool Panel
Custom 4-Drawer Tool Box
Removable Speedlay Hosebeds
Aluminum 4-Way Hose Bed Covers
Encapsulated Roll-Up Door Protection
Suction Hose Storage Sleeve
Wheel Well SCBA Cylinder Storage
Wheel Well Wheel Chock Storage
Drop-Down Ladder Rack
ProVision Rear Observation Camera
Harrison Hydraulic Generator
Power Rewind Electric Cord Reel
Will-Burt Nightscan Light Tower

Emergency Warning Devices

Whelen LED Lightbar
Whelen LED Warning Lights
Whelen Siren
Whelen LED Traffic Directing Light
Whelen LED Warning Lights

Exterior Lighting

LED Marker Lights
LED Step Lights
Whelen LED Tail Lighting
Under Body and Under Cab Lighting
Whelen LED Scene Lighting

Vehicle Dimensions

Overall Height 11' 1"
Overall Length 35'
Wheelbase 226"
Weight with Water 41,550 Lbs.
