CE03 – Tandem Axle Tanker

Gladiator MFD Chassis with 10” Raised Roof, 4-Door, Tandem Axle, CustomFIRE Pumper-Tanker, Aluminum Body, 1500 GPM Pump, Side Mounted Pumper

Please note this is the base model through HGACBuy.   Additional published options are available with each base model


Truck Type :
Cab Type :

Chassis Model

Spartan Gladiator

Apparatus Body

Tandem Aluminum Pumper Body, High Side Driver Side/Low Side Passenger Side
Single Electric Rear Stainless Steel Telescoping Dump Chute and Valve
Direct Rear Tank Fill
Zico Drop Down Folding Tank Compartment, Passenger Side
All Sweep-Out Style Compartments
Roll-up Doors with Anodized Finish
Stainless Steel Underbody Support System and Water Tank Cradle
Enclosed Ladder Storage through the Tank for 24’ Extension, 14’ Roof and 10’ Folding Ladders
Ladders, 24’ Extension, 14’ Roof and 10’ Folding
Filtered Vents in All Compartments
Folding Steps @ Rear and Front Body Bulkheads
Single Color Paint w/ Swirled Interior Body Finish
NFPA Striping and Rear Chevrons

Fire Pump System

Fire Pump, 1500 GPM Waterous CSU C20 Single-Stage
Pressure Controller, FRC Pump Boss
Waterous Oil-less Primer and Main Pump Drain
3” Tank-to-Pump Inlet
One (1) 2.5” Gated Intake, Driver’s Side
Two (2) 2.5” Outlets, Driver’s Side
One (1) 2.5” Outlet, Passenger’s Side
One (1) 3.5” LDH Outlet, Passenger’s Side
One (1) 2.5” Rear Outlet
3” Deluge Gun Outlet Above Pump Area
1” Tank Refill Line
Two (2) 1.75” (200’) Crosslays, 2” Valves / Plumbing
Stainless Steel Pump Module
15’ 5” LDH Suction Sleeve
Independent Third-Party Pump Test

Booster Tank

Water Tank, 3000-Gallon, UPF Poly

Emergency Warning Devices

Whelen LED Warning Light Package including Whelen Freedom LD Lightbar and M6 Surface Mounted Lights
Whelen Electronic Siren w/Speaker Recessed in Front Bumper
Grover Bumper-Mounted Air Horns, Two (2)

Exterior Lighting

Whelen LED Stop/Tail, Turn and Back Up Lights
Whelen LED Compartment Lighting
Pre-Engineered Wiring Harnesses; Color and Function-Coded Wiring
Centralized Power/12V Electrical Distribution Panel
Multi-Pin Aviation Style Electrical Connectors
