Brainerd’s Rescue Pumper

Custom built for Brainerd Fire Department — Brainerd, MN


Truck Type : , ,
Cab Type : ,

Chassis Model

Sutphen Monarch Chassis
Cummins L9 450hp Engine
Allison 3000 EVS Transmission
GVWR 48,000 Lbs.

Apparatus Body

Concealed Bolted Construction
Stainless Steel Subframe
Stainless Steel Body Material
Roll-Up Compartment Doors

Fire Pump System

Waterous CMUC20 2000gpm Midship Mounted Pump
FoamPro 2001 Single Agent Foam System
Trident Air Priming System
Fire Research InControl Pressure Governor
6" Rear Suction
6" and 2.5" Passenger Side Suctions
6" Driver Side Suction
2.5" Front Bumper Preconnect Discharge
2.5" and 2" Speedlay Discharges
2.5" and LDH Passenger Side Discharges
2.5" Rear Discharge
2.5" Driver Side Discharge

Booster Tank

1000-Gallon Water Tank by UPF
20-Gallon Foam Cell

Special Features

Front Bumper Extension with Hosewell
Removable Speedlay Hosebeds
Slide-In Ladder Storage
Slide-In Suction Hose Storage
Wheel Well SCBA Cylinder Storage
Wheel Well Wheel Chock Storage
Adjustable Compartment Shelving
Pull-Out Compartment Trays
Pull-Out Tool Boards
Air Bag Storage Rack
Encapsulated Roll-Up Door Protection
Swing-Out and Down Rear Access Ladder

Emergency Warning Devices

Whelen LED Emergency Lighting
LED Lightbar

Exterior Lighting

Vertical Strip LED Compartment Lighting
LED Step Lighting
LED Marker Lights
Whelen LED Tail Lighting
Under Chassis and Under Body Lighting
Rigid LED Scene Lighting
Whelen LED Scene Lighting

Vehicle Dimensions

Overall Height 10'
Overall Length 32' 8"
Wheelbase 210"
Weight with Water 40,330 Lbs.
