Side Mount Pumper

Custom built for Saint Anthony Village FD — Saint Anthony, MN

Spartan Chassis, Aluminum Body, Waterous 2000gpm Pump, FoamPro Foam System, 650-Gallon Water Tank, Adjustable Compartment Shelving, Pull-Out Compartment Trays and Tool Boards, Slide-In Ladder and Pike Pole Storage, LED Emergency Lighting


Truck Type :
Cab Type :
Deployed : August, 2018

Chassis Model

Spartan MetroStar Chassis
Cummins ISL 450hp Engine
Allison 3000 EVS Transmission

Apparatus Body

Concealed Bolted Construction
Aluminum Body Material
Stainless Steel Subframe
Roll-Up Compartment Doors

Fire Pump System

Waterous CSUC20 2000gpm Midship Mounted Pump
FoamPro 2001 Single Agent Foam System
Fire Research PumpBoss Pressure Governor
Waterous Oil-Less Pump Primer
Front 6" Suction
Passenger Side 6" and 2-1/2" Suctions
Rear 6" Suction
Driver Side 6" Suction
Passenger Side 2-1/2" and LDH Discharges
Rear LDH Discharge
Hosebed 2-1/2" Preconnect Discharge
Front Bumper 2-1/2" Discharge
Speedlay 2" Discharges

Booster Tank

650-Gallon Poly Water Tank by UPF
30-Gallon Foam Cell

Special Features

Front Bumper Extension with Dual Hosewells
Removable Speedlay Hosebeds
On-Board Powered Foam Refill System
Hinged Aluminum Hosebed Covers
Encapsulated Roll-Up Door Protection
Adjustable Compartment Shelving
Pull-Out Compartment Trays
Pull-Out Tool Boards
Multiple Drawer Tool Box
Wheel Well SCBA Cylinder Storage
Slide-In Ladder and Pike Pole Storage
Swing-Out and Down Rear Access Ladder
Smart Power 5.5kW Hydraulic Generator
Power Rewind Electric Cord Reels
Cord Reel Aluminum Enclosure

Emergency Warning Devices

Federal Q2B Mechanical Siren
Whelen LED Lightbar
Whelen LED Traffic Directing Lightbar
Whelen LED Warning Lights
Techniq LED Warning Lights

Exterior Lighting

LED Step Lights
LED Marker Lights
Techniq LED Tail Lighting
Under Cab and Under Body Lights
Rigid Industries LED Scene Lighting
Fire Research Telescoping Scene Lights

Vehicle Dimensions

Overall Height 9' 5"
Overall Length 34' 3"
Wheelbase 17'
Weight with Water 34,530 Lbs.
